Performance Analysis of MGO Panel and Gypsum Panel

1. Composition

Gypsum panel: raw materials for gypsum panel are DSG, starch, foaming agent, kraft paper, etc. Standard paper faced gypsum panel consists of face paper, back paper and gypsum core

MGO panel: MGO panel is composed of magnesium oxide + magnesium chloride + 2 layers of grid cloth + 2 layers of non-woven fabric

2. Fire performance

Gypsum panel: 50mm metal surface gypsum rockwool cleanroom panel fire resistance limit 1h. Combustion performance class A

MGO panel: 50mm metal surface MGO rockwool cleanroom panel fire resistance limit 1h. Combustion performance class A

3. Bending capacity

Gypsum panel: double gypsum rockwool four sides frame panel has a flexural bearing capacity of 1.2-1.3kn/m³

MGO panel: the bending bearing capacity of double MGO rockwool four sides frame panel is 1.2-1.3kn/m³

4. Surface flatness

Gypsum panel: Gypsum panel is divided into right-angled panel surface and wedge-shaped panel surface

MGO panel: the MGO panel uses a right-angled panel surface

5. Adhesive strength

Gypsum panel: the bonding strength of double gypsum rockwool four sides frame panel is 0.13-0.16MPa

MGO panell: the bonding strength of double MGO rockwool four sides frame panel is 0.1-0.13MPa
